STAR TECK XP® cable fittings are designed to accommodate a broad range of cables, thereby minimizing the possibility of mismatched cables and fittings in the field. Highly efficient, highly visible union features twist-on action for easy connection and disconnection; red color assures high visibility, easy recognition. Union also serves as a “puller” during disassembly. Exclusive power grip provides grip that’s high upon cable armour not on first convolution so precise cable preparation is not critical. Non-magnetic stainless steel Power Grip grounding ring assures 360° long-term dependable grounding. Also provides phenomenal tensile pull out resistance.
Working with engineers from the petrochemical, oil and gas industries, Thomas & Betts then introduced the STAR TECK XP fitting.
With an easy-to-fill, integral sealing chamber and a disconnectable design requiring minimal cable preparation, this fitting became the benchmark for ease of installation in hazardous environments.
A line of liquid and putty sealants was also developed at the same time, eliminating the need for the cement sealants used up to this point.
A line of liquid and putty sealants was also developed at the same time, eliminating the need for the cement sealants used up to this point.
Specifications
Brand Name
ABB
Sub Brand
Star Teck
Item Name
Cable Gland
Type
Straight
Trade Size
1/2 in
Conductor Size
0.6 – 0.76 in
Thread Type
NPT
Material
Steel
Finish
Silver and Red
Includes
Locknut, Sealing Ring
Standards
CSA 23086
Application
For Hazardous Locations
UPC
786210309460
Packages
