Copper One-Hole Lug, Long Barrel – Bell Shaped End, Blind End, Max 35kV, Wire Size 3/0 AWG, 1/2 inch Bolt Size, Tin Plated, Die Code 50, Die Color Code Orange.
Specifications
| Brand Name | ABB | Sub Brand | Color-Keyed® |
| Item Name | Compression Lug | Type | Long Barrel – Bell Shaped End |
| Conductor Size | 3/0 AWG | Number of Holes | 1 |
| Stud Size | 1/2 in | Barrel Diameter | 0.63 in |
| Tongue Size | 1-1/4 in L x 0.92 in W x 0.13 in T | Overall Length | 2.7 in |
| Color Code | Orange | Material | Copper |
| Voltage Rating | 35000 V | Barrel Type | Long – Bell Shaped End/Blind End |
| Tongue Type | Straight | Die Code | 50 |
| Finish | Tin Plated | Application | For Copper Conductors |
| UPC | 786210962894 |
