Liquid Tight Flexible Metallic Conduit, General Purpose, Galvanised Steel Core with PVC Jacket, Conduit Size 3/8 Inch, Length 30 Meters/100 Feet, Working Temperature -30 to 80 Degrees C, UL E125517, CSA LR-72635, Compliant to RoHS, Gray.General Purpose, UL Listed Liquid-tight FlexibleMetallic Conduits providing premier performance inthe toughest applications.PRODUCT FEATURES:-Coordinated performance with Ser. 52/53 Steel Fittings -Smooth extruded jackets provide best performance with fittings -Used extensively in machine tool and other industrial environments where flexibilityis necessary for motion, vibration and bending -Listed and marked for direct burial in earth or in poured concrete -Liquid-tight applications against water, oils, cutting fluids and mild acids
General Purpose, UL Listed Liquid-tight FlexibleMetallic Conduits providing premier performance inthe toughest applications
Specifications
Brand Name
ABB
Sub Brand
B Liquidtight Systems,T
Item Name
Liquid Tight Metallic Conduit
Type
Flexible
Trade Size
3/8 in
Length
100 ft
Diameter
0.484 in ID x 0.71 in OD
Material
Galvanised Steel
Color
Gray
Finish
PVC Coated
Bend Radius
51 mm
Standards
UL E125517, CSA LR-72635 Certified, RoHS Compliant
Application
For General Purpose Application
UPC
786210108391
