FEATURES
- Bosch 0986AH0307 Change Over Micro Relay, 5 Pins, 12V, 30/10A, Resistor
- Developed to be durable and robust through accurate processing and the use of ideal-quality materials: allows for up to 100.000 switching cycles
- Temperature resistant design: provides the ability to cope with ambient temperatures reaching from -40 Degree C up to +100 Degree C
- Base plate and housing made from fiber-reinforced polyamide: High corrosion resistance.
DESCRIPTION
Bosch 0986AH0307 Change Over Micro Relay, 5 Pins, 12V, 30/10A, Resistor
SPECIFICATIONS
| Type | Change Over |
| Mounting Bracket | N/A |
| Resistor | Yes |
| Diode | N/A |
| Life durability | 100.000 |
| Current | 30/10 Amps |
| Voltage | 12 V |
| Number of Pins | 5 |
| Housing | Plastic Housing |
| Temp Range | -40 ~ +100 C |
OE NUMBER
HYUNDAI: 952302P040
TOYOTA: 9008087020, 9008987009, 9098704004
