Features Lightweight and compact clamp exclusively for horizontal hanging. Easy to do upright work. The clamp has a lock spring, so it will not come off even when there is no load.
Use Elevating and transporting shaped steel.
Specification Basic working load (t): 2.0Clamping range (mm): 3 to 25Dimensions (mm)D: 50Dimensions (mm)H: 134Dimensions (mm)H2: 60Dimensions (mm)L: 146Height (mm): 134Width (mm): 146
Specification2 With lock spring For horizontal hanging only For 2-point hanging
Material/Finish
Set contents/accessories
caution Please use this clamp only in the specified direction. Otherwise, it cannot be used as the cam will not generate any “force” and there is a risk of it coming off. When lifting long objects (over 2m), use two-point suspension, and be sure to attach the clamps in the same direction. When lifting a structure, use a balance so that the hanging angle is 0 , and lift the structure within 20 .
