APPLICATION: Incandescent lights; Halogen lights; Fluorescent lights; CFLs; Electronic ballasts; Motors (up to 1 HP).DIMENSIONS: Dimensions (in.) 113/16 in. wide x 223/32 in. high x 113/16 in. deep.ELECTRICAL RATINGS: Maximum Load1800 W resistive or inductive, 1 HP motor @120 V; Inductive Load15 A @ 120 Vac; Resistive Load1800 W @ 120 Vac.ELECTRICAL CONNECTIONS: Single pole 3 wire (line, load, neutral); Multiswitch (3way), 4 wire (line, load, neutral, threeway).AMBIENT TEMPERATURE RANGE: Operating: 5 F to 122 FPROGRAMMABILITY: Weekly/Daily Programming (21 on, 21 off); Solar timetable; Random.OPERATING MODE: Manual (conventional on/off switch); Automatic; Random
Specifications
| Brand Name | Honeywell | Item Name | Programmable Wall Switch with Solar Time Table |
| Type | 3 Way, 4-Wire, Manual/Automatic, Random | Voltage Rating | 120 V |
| Amperage Rating | 15 A | Wattage | 1800 W |
| HP Rating | 1 hp | Time Setting Range | 7 dy |
| Number of Poles | 1 | Frequency Rating | 60 Hz |
| Color | White | Dimensions | 1-13/16 in W x 1-13/16 in D x 2-23/32 in H |
| Mounting | Screw, Wall Duct | Temperature Rating | -15 to 50 °C |
| Application | For Incandescent, Halogen, Fluorescent Lights, CFLs, Electronic Ballasts, Motors (up to 1 hp) |
