Description:
- Powerful 2.5 HP, 230V motor
- Heavy-duty cast-iron table and extension tables are double ground for accuracy and finish
- Riving knife system for maximum operator safety
- Table has “T” slots for miter gauge and beveled front edge
- Magnetic safety switch
- Large 8″ diameter chromed handwheels with center locking knobs
- Comes with 10″ x 40 tooth carbide tipped saw blade, cast-iron miter gauge, standard and dado inserts, push stick storage hooks and hex. keys
- Choice of two Duo-Fence Industrial Rip Fence Systems, 30″ max rip capacity
Specifications:
- BLADE DIAMETER: 10″
- BLADE TILTS: Left
- DEPTH OF CUT AT: 45°2-3/16″
- DEPTH OF CUT AT: 90°3-1/8″
- TABLE SIZE WITH EXTENSIONS: 40″ x 27″
- DIAMETER OF ARBOR: 5/8″
- ARBOR SPEED (RPM): 3,850
- MOTOR: 2.5 HP, 9.6 Amp.
- VOLTAGE: 230V, 1 phase, 60 Hz
