Description:
- Powerful 1 HP motor
- Line interruption electro-mechanical switch needs a restart after a power failure
- Spindle is supported by high quality ball bearings
- Cast-iron pulleys reduce vibrations
- 45° tilting table for angular drilling
- Non-slip rubber feed handles
- 12 speeds
- Light socket incorporated into drill press head (standard light bulb not included)
Specifications:
- CAPACITY: 1-1/4″
- CHUCK SIZE: 3/4″
- SWING: 22″
- STROKE: 4-3/4″
- MAX. DISTANCE FROM CHUCK TO TABLE: 21-3/4″
- MAX. DISTANCE FROM CHUCK TO BASE: 41-7/8″
- TABLE SIZE: 18-3/4″ x 16-1/4″
- SIZE OF T-SLOT ON TABLE: 5/8″
- SPINDLE TAPER: MT 4
- QUILL DIAMETER: 75 mm
