Features & Benefits:
- Trigger Switch with Lock-On Button (AC/DC)
- Heavy duty torque limiter prevents damage to internal gearing and prevents operator from experiencing a surge of torque during wheel lock up
- Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
- Includes rear vent “Dust Cover Assembly” for added protection against dust and debris
- Motor winding protection features “Zig-Zag” varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
- Rear handle swivels 180o to adjust to the most comfortable grinding position
- Rotatable gear housing can be positioned at every 90o for optimal positioning
- Removable side handle can be mounted on left or right side of tool
- Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Specifications:
- Maximum Capacities:
- Grinding Wheel — 7″ (180 mm)
- Sanding Disc — 7″ (180 mm)
- Wire Cup Brush — 4-3/8″ (110 mm)
- Spindle Thread — 5/8″ – 11 UNC
- No Load Speed –8,500 RPM
- AMPS (120V) –15.0 A
- Vibration Level –(Unavailable)
- Noise Level –(Unavailable)
- Overall Length –19-7/8″ (504 mm)
- Net Weight –13.9 lbs (6.3 kg)
Standard Equipment:
Anti-Vibration Side Handle (194543-3), Dust Cover Attachment Set (194289-1), Lock Nut Wrench 28 (782412-6), Toolless Wheel Cover (123542-8), Inner Flange (224317-9), Lock Nut 5/8-45 (224568-4)
