Features & Benefits:
- Ideal For Trim And Flooring Applications
- Sliding Rail Mechanism incorporating 4 Linear Ball Bearings provides increased rigidity to produce precise, adjustment free cuts right out of the box
- Electric Brake for increased operator safety
- Mitre Capacity of 47o Left or 57o Right with Positive Stops at 0o, 15o, 22.5o, 30o & 45o
- Bevel Capacity of 45o Left or 5o Right
Specifications:
- Blade Diameter –7-1/2″ (190 mm)
- Arbor –5/8″ (15.88 mm)
- No Load Speed –6,000 RPM
- AMPS (120V) –10.0 A
- Vibration Level –2.5 m/s2
- Noise Level –92 dB(A)
- Dimensions (L xW x H)–17″ x 26-3/8″ x 18″ (430 mm x 670 mm x 458 mm)
- Net Weight –28.9 lbs (13.1 kg)
Standard Equipment:
7-1/2 C.T. Blade 40T (A-90629), Hex Wrench 5 (783203-8), Triangle rule (762001-3), Dust Bag (122852-0), Two Safety Switch Button (411478-6), Vertical Vise (122571-8), Two Holders (322312-4)
