Meccalte uCharge automatic battery charger provide a cost-effective solution to most industrial battery charging requirements. Utilising the latest high-efficiency switch-mode technology and microprocessor control is suitable for charging most sealed or flooded batteries and is easily calibrated by the end-user to suit the battery type.
The multi-stage intelligent charging characteristic ensures accurate and efficient battery charging and designed for permanent connection to the batteries, maintaining them in a fully charged condition without overcharging.
Specifications
| Input Range V | 90 – 264V AC |
|---|---|
| Frequency | 47 – 63Hz |
| Input Current | 1.5A rms max. |
| Leakage Current | None |
| Output Voltage / Current | 12.0V Nominal 6.0Apk |
| Ripple and Noise | 0.5% |
| Overload Protection | Constant current limit / fold back |
| Working Temperature | -10C to +50C |
| Weight | 400 grams |
| Dimensions (LxWxH) | 77 x 42 x 116 mm |
| Warranty (RTB) | 12 months |
