Clarity 5E Premium Category 5e Modular Patch Cord, blue, 3′, four-pair UTP stranded 24 AWG PVC/CM, center tuned with Clarity 5E connecting hardware for optimum Category 5e installed performance using Ortronics Paralign 2 pair-positioning technology.FEATURES:• ETL third party tested and verified to TIA/EIA 568B.2 Category 5e component specifications: Ensures Category 5e component performance. • Each cord is factory tested: Ensures every cord shipped meets Category 6 component specifications. • Center tuned technology: Elevates the performance of Clarity 6 connector union. • Paralign 2 pair-positioning technology: Maintains pair integrity through the plug termination allowing mating hardware to be designed/tuned to these cords.• Snagless plug design: Protects plugs when pulling through pathways or cable managers.• Premium conductor cordage: Reliable performance and durable cord life.• Compatible with both T568A and T568B wiring: Provides universal wiring ability.• Improved signal to noise ratio: More transparent signal path is field measurable in a link or channel.• Backwards compatible to Category 3, 5, and 5e: Supports lower category installations and components.
Center tuned to Clarity jacks and panels for a more transparent mated union
Narrow Paralign plug profile supports use in high density panels and hubs
Paralign™ 2 plug termination better controls plug performance
Icon compatible – provides additional TIA-606-A designation capabilities
Assembled with premium cordage, 100% factory tested for performance, reliability and long life
Specifications
Brand Name
Ortronics
Sub Brand
Clarity®
Item Name
Patch Cord
Type
4-Pair, Category 5E, Modular, Premium
Cable Type
24 AWG UTP Stranded
Cable Length
3 ft
Connector Type
RJ45 Plug x RJ45 Plug
Number of Poles
4
Material
Copper
Power Rating
100 W
Cable Material
PVC
Bend Radius
1 in
Color
Blue
Standards
ETL Listed, RoHS Compliant, TIA-606-A Standard
Application
For Commercial, Industrial
UPC
662875449935
Packages
