FEATURES AND BENEFITS: • Impact-resistant polycarb back body and frame. • Cushioned thermoplastic paddle assures smooth, quiet, long term operation. • Unique single rocking butterfly contact provides long term consistent performance with significantly fewer moving parts. • Internal screw-pressure-plate back and side wire capability for easy installation with 14 – 10 stranded or solid copper/copper clad wire. • Terminals made of high conductivity brass and serrated for maximum wire gripping. • Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance. • Integral auto-ground clip for positive ground to metal boxes. • Tri-drive ground, terminal, and mounting screws. • All terminal screws backed out, ready-to-install.
Specifications
| Brand Name | Pass & Seymour | Sub Brand | Pass & Seymour |
| Item Name | Specification Grade Decorator Switch | Type | Decorator,Switch |
| Voltage Rating | 120 – 277 VAC | Amperage Rating | 15 A |
| Contact Configuration | SPST | Number of Poles | 1 |
| Power Rating | 1 W | Contact Rating | 120 V |
| Actuator | Rocker/Button | Mounting | Screw Mount |
| Connection | Back and Side Wired | Terminal Type | Screw |
| Material | Thermoplastic | Color | Gray |
| Finish | Gloss | Dimensions | 4-1/4 in |
| Standards | UL20 Listed, CSA C22.2 111 Certified, RoHS Compliant | Application | For Industrial Use |
| UPC | 785007539028 |
