FEATURES AND BENEFITS: • Impact-resistant polycarb back body and frame. • Cushioned thermoplastic paddle assures smooth, quiet, long term operation. • Unique single rocking butterfly contact provides long term consistent performance with significantly fewer moving parts. • Internal screw-pressure-plate back and side wire capability for easy installation with 14 – 10 stranded or solid copper/copper clad wire. • Terminals made of high conductivity brass and serrated for maximum wire gripping. • Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance. • Integral auto-ground clip for positive ground to metal boxes. • Tri-drive ground, terminal, and mounting screws. • All terminal screws backed out, ready-to-install.
Impact-resistant polycarb back body and frame.
Cushioned thermoplastic paddle assures smooth, quiet, long term operation.
Unique single rocking butterfly contact provides long term consistent performance with significantly fewer moving parts.
Internal screw-pressure-plate back and side wire capability for easy installation with 14 – 10 stranded or solid copper/copper clad wire.
Terminals made of high conductivity brass and serrated for maximum wire gripping.
Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance.
Integral auto-ground clip for positive ground to metal boxes.
Tri-drive ground, terminal, and mounting screws.
All terminal screws backed out, ready-to-install.
For covering patents, see www.legrand.us/patents.
Specifications
Brand Name
Pass & Seymour
Sub Brand
Pass & Seymour
Item Name
Decorator Switch
Type
Decorator,Switch
Grade
Industrial
Voltage Rating
120 – 277 VAC
Amperage Rating
20 A
Number of Poles
2
Actuator
Paddle
Load Type
CFL,Fluorescent,Halogen,Incandescent,LED,Universal,Xenon
Contact Rating
120 V
Terminal Connection
Grounded
Material
Thermoplastic
Color
Brown
Finish
Matte
Dimensions
4.25 in
Mounting Type
Wallbox
Standards
UL 20
Application
Commercial,Industrial
UPC
785007539400
Packages
