This 6″ Jointer features a helical cutterhead with 40 four-sided indexable carbide knife inserts – this design provides a superior finish and quieter operation compared to conventional cutterheads, and the inserts require no adjustment once they are installed. If a knife insert becomes nicked, simply rotate it for a fresh edge and continue working. Oversized infeed/outfeed tables are mounted on dovetailed ways. The fence is 38″ in length, with positive stops at 90° and 45° right and left. The fine/quick adjustment lever on the infeed table offers quick set-ups with precision controlled depth of cut. The heavy steel stand features a 1 HP motor with a non-slip v-belt drive for maximum performance. The 4″ dust port offers easy connection to any dust collection system.
- Helical cutterhead with four-sided knife inserts provides smoother, quieter cutting and finer finish than conventional systems
- 66″ long adjustable infeed and outfeed tables provide more working surface
- Fine/quick adjustment lever on infeed table for precision cuts
- Extra-long 38″ two-way tilting fence with positive stops provides quick positioning for 90° or bevel cuts
- Enlarged sheet metal stand provides a sturdy base
- 1HP motor offers plenty of power
- Fence controls are center-mounted for convenience
- Push button switch is lockable to prevent accidental starting
- 4″ port for dust collection
- Standard Equipment:
- 1HP TEFC Motor
Specifications:Number of Carbide Cutters: 40Cutterhead Speed: 6,000 RPMCutting Capacity: 6″Table Size: 66″ x 7-1/4″Table Height from Floor: 31-1/2″Infeed Table Length: 32-1/2″Outfeed Table Length: 32-1/2″Fence Size: 38″ x 4″Fence Tilt Degrees: 45 Forward, 45 BackwardFence Positive Stops: 45, 90, -45Dust Collection Minimum CFM Required: 800Dust Port Outside Diameter: 4″Motor Power: 1 HPMotor Voltage: 115/230Prewired Voltage: 115Motor Amps: 13/6-1/2
Powermatic stock number 1791317K
