PRODUCT FEATURES:- Manufactured from high strength aluminum alloy- Dual rated for aluminum and copper conductors, 600 Volt, 90°C- Wide conductor range: 750 kcmil – 14 Sol.- Allows exibility in the eld and reduces number of connectors in inventory- Multiple conductor congurations: 2 through 14 position- Suitable for use in panelboards, cable trays, raceways, ducts and troughs- Pre-lled with oxide inhibitor, prevents oxidation, moisture and contaminants from entering contact area- Supplied with removable access plugs over screw and conductor ports providing protection against contaminants- Pre-insulated at factory with high dielectric strength plastisol- Clear insulation allows for visual conrmation that conductor is properly inserted- Saves time, eliminates taping, reduces overall installation costs- Abrasion and chemical resistant- Will not support combustion
Specifications
| Brand Name | Techspan | Item Name | Pre Insulated Power Bar |
| Voltage Rating | 600 V | Conductor Size | 14 AWG |
| Overall Length | 1.03 in | Type | Single-Sided, Type IPB-S |
| Contact Material | Aluminium Alloy | Insulating Material | Plastisol |
| Color | Black | Temperature Rating | 90 °C |
| Standards | UL Listed, CSA Certified, RoHS Compliant | Application | For Use in Panelboards, Cable Trays, Raceways, Ducts and Troughs |
| UPC | 776856266760 |
